TRD Nylon Tiles – Cut Pile

TRD Specifications
Construction1/10” Cut Pile Frieze
Yarn Composition100% Solution Dyed Nylon
Tufted Pile WeightCa. 1018 g/m² (30 oz/yd²)
Total WeightCa. 3600 g/m² (106 oz/yd²)
Pile HeightCa. 5.5 mm
Total HeightCa. 11 mm
Primary Backing ClothNon-woven Polyester Spunbonded
BackingPLE® Cushion Backing (PVC-Free)
Tile Size50 cm x 50 cm
Packing20 pcs Or 16 pcs per box (5 m²)
Performance (as tested by ITTS Inc. USA)
Stain Resistance10 (AATCC-175-2003)
Abrasion ResistancePass – 4 (ASTM-D-7330)
Static ControlPass – Max. 4 kV (AATCC-134-1996)
Tuft BindPass – 4.4 lbs (ASTM-D-1335)
Dimensional StabilityPass – Max. 0.1% change (AACHEN)
Indoor Air Quality (V.O.C.)Pass – No VOC Detected (ASTM-D5116-10)
Impact Sound InsulationΔLᴡ: 28 dB (ISO 10140)
Sound Absorptionαᴡ = 0,30 (H) (ISO 354)
Hz 125 250 500 1000 2000 4000
αs 0.05 0.05 0.40 0.30 0.35 0.50
Anti-soil & Anti-oil Treatment3M Scotchgard™ Protector
Flammability
– Radiant PanelPass – Class I (ASTM-E-648)
– Pill TestPass – 8 (ASTM-D-2859)
– Smoke DensityPass – Max. 450 (ASTM-E-662)
Colourfastness
– to lightExcellent – 5 (AATCC-16E)
– to wet & dry crockingExcellent – 5 (AATCC-165)
– to ozoneExcellent – 5 (AATCC-129)
Lifetime Anti-shock Carpet Warranty
Ideal for Contract Use.
The subfloor should be dry, smooth, flat, dust-free and resistant to compression and load-bearing. The seams may remain visible to the eye and this should be accepted as an inherent characteristic of carpet tiles. Due to dye lot variations, actual colour may vary slightly from the samples. Chair pads are recommended to prevent premature wear of carpet.
Environment
The design and production of Trend Tile conforms to the ISO 14001:2004 Environmental Management System and complies with environmental regulations.

As a responsible manufacturer and to minimize our carbon footprint, a majority of our excess production materials are recycled in-house resulting in a minimum of 10% recycled content in our tile backing. Trend Tile does not contain any PVC in its manufactured materials and packaging.

TRD Tile is an environmentally friendly “green” carpet.
