MEL-6 Carpet Planks


MEL-6 Specifications

Contruction 1/10” Level Loop Pile
Yarn Composition 100% Solution Dyed Olefin
Tufted Pile Weight Ca. 542 g/m² (16 oz/yd²) (+/- 10%)
Total Weight Ca. 3600 g/m² (105 oz/yd²)
Pile Height Ca. 3 mm (+/- 0.5 mm)
Total Height Ca. 5 mm (+/- 0.5 mm)
Stitch Rate 11 per inch
Backing ECO Back – “PVC Free”
Plank Size 25 cm x 100 cm
Packing 20 pcs per box (5 m²)
Performance (as tested by ITTS Inc. USA)
Stain Resistance 10 (AATCC-175-2003)
Static Control Pass – Max. 4 kV (AATCC-134-1996)
Tuft Bind Pass – 8.8 lbs (ASTM-D-1335)
Dimensional Stability Pass – Max. 0.1% change (AACHEN)
Indoor Air Quality (V.O.C.) Pass – No VOC Detected (ASTM-D5116-10)
Impact Noise Rating ΔL: 26 dB (ISO 10140)
Sound Absorption αw 0.20 (ISO 354)
Hz 125 250 500 1000 2000 4000
αs 0.01 0.03 0.08 0.28 0.35 0.43
– Radiant Panel Pass – Class I (ASTM-E-648-06)
– Pill Test Pass – 8 (ASTM-D-2859-06)
– Smoke Density Pass – Max. 450 (ASTM-E-662-06)
– to light Excellent – 5 (AATCC-16E)
– to wet & dry crocking Excellent – 5 (AATCC-165)
– to ozone Excellent – 5 (AATCC-129)
Lifetime Anti-shock Carpet Warranty
Ideal for Medium Contract Use.
The subfloor should be dry, smooth, flat, dust-free and resistant to compression and load-bearing. Where seaming is necessary, a seam sealant must be used for all such installations. Due to dye lot variations, actual color may vary slightly from the samples. Chair pads are recommended to prevent premature wear of carpet.
The design and production of MEL-6 Tile conforms to the ISO 14001:2004 Environmental Management System and complies with environmental regulations.

As a responsible manufacturer and to minimize our carbon footprint, a majority of our excess production materials are recycled in-house resulting in a minimum of 10% recycled content in our tile backing. MEL-6 Tile does not contain any PVC in its manufactured materials and packaging.

MEL-6 Tile is an environmentally friendly “green” carpet
