| MAN-7 Specifications | ||
| Construction | 1/12” Multi-Level Loop Graphic | |
| Yarn Composition | 100% Solution Dyed Olefin | |
| Tufted Pile Weight | Ca. 610 g/m² (18 oz/yd²) (+/- 10%) | |
| Total Weight | Ca. 3400 g/m² (100 oz/yd²) | |
| Pile Height | Ca. 4 mm (+/- 0.5 mm) | |
| Total Height | Ca. 6 mm (+/- 0.5 mm) | |
| Density | 5486 | |
| Backing | ECO Back – “PVC Free” | |
| Tile Size | 50 cm x 50 cm | |
| Packing | 20 pcs per box (5 m²) | |
| Performance | (as tested by ITTS Inc. USA) | |
| Stain Resistance | 9 (AATCC-175-2003) | |
| Static Control | Pass – Max. 4 kV (AATCC-134-1996) | |
| Tuft Bind | Pass – 8 lbs (ASTM-D-1335) | |
| Dimensional Stability | Pass – Max. 0.1% change (AACHEN) | |
| Pass – No VOC Detected (ASTM-D5116-10) | ||
| ΔL: 26 dB (ISO 10140) | ||
| αw 0.20 (ISO 354) | ||
| Hz 125 250 500 1000 2000 4000 | ||
| αs 0.01 0.03 0.08 0.28 0.35 0.43 | ||
| Flammability | ||
| – Radiant Panel | Pass – Class II (ASTM-E-648-06) | |
| – Pill Test | Pass – 8 (ASTM-D-2859-06) | |
| – Smoke Density | Pass – Max. 450 (ASTM-E-662-06) | |
| Colourfastness | ||
| – to light | Excellent – 5 (AATCC-16E) | |
| – to wet & dry crocking | Excellent – 5 (AATCC-165) | |
| – to ozone | Excellent – 5 (AATCC-129) | |
| Lifetime Anti-shock Carpet Warranty | ||
| Ideal for Medium Contract Use. | ||
| The subfloor should be dry, smooth, flat, dust-free and resistant to compression and load-bearing. Where seaming is necessary, a seam sealant must be used for all such installations. Due to dye lot variations, actual color may vary slightly from the samples. Chair pads are recommended to prevent premature wear of carpet. | ||
| Environment | ||
| The design and production of MAN-7 Tile conforms to the ISO 14001:2004 Environmental Management System and complies with environmental regulations.
As a responsible manufacturer and to minimize our carbon footprint, a majority of our excess production materials are recycled in-house resulting in a minimum of 10% recycled content in our tile backing. MAN-7 Tile does not contain any PVC in its manufactured materials and packaging. MAN-7 Tile is an environmentally friendly “green” carpet. |
||
 |
