M-LINE Nylon Tiles


M-LINE Specifications
Construction Tufted 1/10” Loop
Yarn Composition
50% PA6 Solution Dyed Aqualon + 50% PA6 Space Dyed
Secondary Backing Back2Back: Modified bitumen enhanced with a thermoplastic elastomer, reinforced with a glass fibre fleece covered with 100% PES fleece 10% recycled content included.
Tufted Pile Weight Ca. 550 g/m²
Total Weight Ca. 4400 g/m²
Pile Above Backing Ca. 309 g/m²
Pile Height Ca. 2.5 mm
Total Height Ca. 5.7 mm
Pile Density Ca. 0.124 g/m³
Tuft Density Ca. 168,000 g/m²
Tile Size 50 cm x 50 cm
Packing 20 pcs per box (5 m²)
Indoor Air Quality (V.O.C.) Pass – No V.O.C Detected (ASTM-D5116-10)
Fire Resistance Bfl-s1 (EN 13501-1)
Fastness To Light > 7 (ISO 105-B02)
Rubbing Fastness ≥ 4 (EN ISO 105-X12)
Colour Fastness To Water ≥ 4 (EN ISO 105-E01)
Thermal Resistance 0.05 m² K/W (ISO 8302)
Impact Noise Rating ΔL: 36 dB (ISO 10140)
Sound Absorption αw 0.15 (ISO 354)
Hz 125 250 500 1000 2000 4000
αs 0.03 0.02 0.05 0.16 0.26 0.35
Permanent Anti-static ≤ 2 kV (ISO 6356)
Transversal Resistance ≤ 10⁹Ohm (ISO/DIS 10965)
Dimensional Stability Max. 0.2 % (EN 986)
Castor Chair Suitability A : continuous use (EN 985)
Classification 33 – LC1 (EN 1307)
Données Environnementales Démarche HQE® : cf. FDES suivant NF P01-010 Déclaration du 30/07/2003
LEED® Product contributes toward satisfying Credits 4.3 under LEED®. Products are not reviewed under LEED®, LEED® credit requirements cover the performance of materials in aggregate, not the performance of individual products of brands. Fore more information on LEED®, visit www.usgbc.org/contact
Lifetime Anti-Static Shock Warranty.
Ideal for Heavy Contract Use.
The subfloor should be dry, smooth, flat, dust-free and resistant to compression and load-bearing. Where seaming is necessary, a seam sealant must be used for all such installations. Due to dye lot variations, actual colour may vary slightly from the samples. Chair pads are recommended to prevent premature wear of carpet.
