M-LINE Nylon Tiles



M-LINE Specifications
ConstructionTufted 1/10” Loop
Yarn Composition
50% PA6 Solution Dyed Aqualon + 50% PA6 Space Dyed
Secondary BackingBack2Back: Modified bitumen enhanced with a thermoplastic elastomer, reinforced with a glass fibre fleece covered with 100% PES fleece 10% recycled content included.
Tufted Pile WeightCa. 550 g/m²
Total WeightCa. 4400 g/m²
Pile Above BackingCa. 309 g/m²
Pile HeightCa. 2.5 mm
Total HeightCa. 5.7 mm
Pile DensityCa. 0.124 g/m³
Tuft DensityCa. 168,000 g/m²
Tile Size50 cm x 50 cm
Packing20 pcs per box (5 m²)
Performance
Indoor Air Quality (V.O.C.)Pass – No V.O.C Detected (ASTM-D5116-10)
Fire ResistanceBfl-s1 (EN 13501-1)
Fastness To Light> 7 (ISO 105-B02)
Rubbing Fastness≥ 4 (EN ISO 105-X12)
Colour Fastness To Water≥ 4 (EN ISO 105-E01)
Thermal Resistance0.05 m² K/W (ISO 8302)
Impact Noise RatingΔL: 36 dB (ISO 10140)
Sound Absorptionαw 0.15 (ISO 354)
Hz 125 250 500 1000 2000 4000
αs 0.03 0.02 0.05 0.16 0.26 0.35
Permanent Anti-static≤ 2 kV (ISO 6356)
Transversal Resistance≤ 10⁹Ohm (ISO/DIS 10965)
Dimensional StabilityMax. 0.2 % (EN 986)
Castor Chair SuitabilityA : continuous use (EN 985)
Classification33 – LC1 (EN 1307)
GUT-NRBA09EE5D
BREENP 428
Données EnvironnementalesDémarche HQE® : cf. FDES suivant NF P01-010 Déclaration du 30/07/2003
LEED®Product contributes toward satisfying Credits 4.3 under LEED®. Products are not reviewed under LEED®, LEED® credit requirements cover the performance of materials in aggregate, not the performance of individual products of brands. Fore more information on LEED®, visit www.usgbc.org/contact
Lifetime Anti-Static Shock Warranty.
Ideal for Heavy Contract Use.
The subfloor should be dry, smooth, flat, dust-free and resistant to compression and load-bearing. Where seaming is necessary, a seam sealant must be used for all such installations. Due to dye lot variations, actual colour may vary slightly from the samples. Chair pads are recommended to prevent premature wear of carpet.
